The Dynamic Lung panel displays lung compliance, airway resistance, and patient-triggering in synchrony with the actual breaths.
The Speak Valve option gives tracheostomized patients a voice and allows them to swallow even while receiving respiratory support from the ventilator.
The ventilator’s monitoring, triggering, and alarm management are adjusted for compatibility with speaking valves in pressure‑controlled modes (PCV+, SPONT, PSIMV+).
With its high‑performance turbine, battery, compact size, and state‑of‑the‑art ventilation modes, the HAMILTON‑C1 is also at your patient’s side for their first steps out of bed.
| Patient groups | Adult/Ped, Neonatal |
|---|---|
| Dimensions (W x D x H) | 310 x 210 x 245 mm (ventilation unit) 630 x 630 x 1380 mm (incl. trolley) |
| Weight | 4.9 kg (10.8 lb) 16.9 kg (37.3 lb) with trolley |
| Monitor size and resolution | 8.4 in (214 mm) diagonal 640 x 480 pixels |
| Detachable monitor | |
| Battery operating time | 4 h with one battery |
| Hot‑swappable battery | |
| Air supply | Integrated turbine |
| O2 connector | DISS (CGA 1240) or NIST |
| Connectivity | CO2/Nurse Call/COM1, CO2/SpO2/COM1, CO2/SpO2/Humidifier & COM1, USB port, RJ‑45 Ethernet port |
| Loudness | 43 dB in normal operation |
| Volume controlled, flow controlled | |
|---|---|
| Volume targeted, adaptive pressure controlled | |
| Pressure‑controlled | |
| Intelligent ventilation | ASV®, INTELLiVENT®‑ASV® (option) |
| Noninvasive ventilation | Option |
| High flow oxygen therapy | Option |
| Visualization of lung mechanics (Dynamic Lung) | |
|---|---|
| Visualization of the patient’s ventilator dependence (VentStatus) | |
| Volumetric Capnography | |
| SpO2 monitoring | |
| Lung stress and strain monitoring (Lung Impact panel) | Option |
| Transpulmonary pressure monitoring | Option |
| Recruitability assessment and lung recruitment (P/V Tool Pro) | |
|---|---|
| Patient‑ventilator synchronization (IntelliSync+) | Option |
| CPR ventilation | |
| Hamilton Connect Module | Option |
| Suctioning tool | |
| SpeakValve compatibility | Option |
| On‑screen help | |
| O2 assist | Option |
| Remote connection to HAMILTON‑H900 humidifier | Option |
|---|---|
| Integrated IntelliCuff cuff pressure controller | |
| Integrated pneumatic nebulizer | |
| Integrated Aerogen nebulizer | |
| Compatibility with Sedaconda ACD anesthetic delivery system |
We are constantly working on further evolving our products. New features are added and existing features improved to ensure you always have access to the latest ventilation technology over your ventilator’s lifetime.
